Flooring
Structural Plywood Flooring
Plywood flooring is an all-purpose bonded structural plywood panel designed for use in domestic, commercial and industrial applications.
Available options for flooring plywood include both structural hardwood and structural pine.
Superior strength and stiffness relative to weight, translates to a thinner panel when compared to particleboard for the same application and there is the option to have full length tongue and grooving to enable easy keying of panels.
Structural Pine Plywood
CD Structural – F11 ECOPly Pine A-Bond
ECOPly is fit for use in structural load bearing applications where the stress rating of the plywood meets the relevant building code requirement for that application. The manufacturer Carter Holt Harvey (CHH) is FSC Certified.
Sheet Details (Click to Expand)
| Length x Width (mm) | Thickness (mm) | Sheet Weight (Kg's) | Image |
| Specification Sheet CD ECOPly | |||
| 2400 x 1200 | 7 | 10.6 |  |
| 2400 x 1200 | 9 | 13.6 | |
| 2400 x 1200 | 12 | 18.1 | |
| 2400 x 1200 | 15* | 22.7 | |
| 2400 x 1200 | 17* | 25.7 | |
| 2400 x 1200 | 19* | 28.7 | |
| 2400 x 1200 | 21 | 31.8 | |
| 2400 x 1200 | 25 | 37.8 | |
| 2700 x 1200 | 7 | 11.9 | |
| 2700 x 1200 | 9 | 15.3 | |
| 2700 x 1200 | 12 | 20.4 | |
| 2700 x 1200 | 15 | 25.5 | |
| 2700 x 1200 | 17 | 28.9 | |
| 2700 x 1200 | 19 | 32.3 | |
| 2700 x 1200 | 21 | 35.7 | |
| 2700 x 1200 | 25 | 42.5 | |
| * In stock |
For more information on Plywood SpecificationsÂ
Structural Hardwood Plywood
CD Structural – F17 Hardwood A-Bond
Fit for use in structural load bearing applications where the stress rating of the plywood meets the relevant building code requirement for that application. This flat, sturdy and stable panel is suitable for tough working conditions requiring impervious durability and is BSI Certified.
Sheet Details (Click to Expand)
| Length x Width (mm) | Thickness (mm) | Sheet Weights (Kg's) | Image |
| Specification Sheet CD Hardwood | |||
| 2400 x 1200 | 12 | 23.2 |  |
| 2400 x 1200 | 15 | 29.2 | |
| 2400 x 1200 | 17 | 33.0 | |
| 2400 x 1200 | 19 | 36.9 | |
| 2400 x 1200 | 21 | 40.8 | |
| 2400 x 1200 | 25 | 48.6 |
For more information on Plywood SpecificationsÂ
Gallery
For more information of flooring design and installation methods, please visit the ECOPly Specification & Installation Guideline.
Click on photos to enlarge
Engineered Wood Product Association of Australasia, 2020
Technical Information
| Flooring | |
|---|---|
| Plywood Technical Information | Specifications |
| Structural Plywood - Design Guide | Engineered Wood Products Association of Australasia |
| Fire Resistance | Engineered Wood Products Association of Australasia |
